SPIN QRE/F

230 V Automation for up-and-over garage doors up to 10/16 m². Opening in 21 s

100SPINQRE 230 V garage door opener with limit switch and encoder complete with built-in electronic control unit and 433,92 MHz two-channel radio receiver.

100SPINF 230 V garage door opener with limit switch.

Motor power supply

FEATURES

• residential use
• 230 V motor
• built-in limit switch
• electronic control unit with built-in radio receiver
• manual release mechanism
• courtesy light with time delay
• built-in open/close buttons (SPINQRE)

PROS

• semi-intensive use
• in accordance with EN 12453 standards
• higher torque and power
• encoder for obstacle detection and crush prevention
• irreversible gate operator
• small and compact to grant the widest opening of the garage door

PRACTICALITY OF USE

The door opener with builtin electronic control unit features two pushbuttons to open/close the door from the inside, as well as an efficient courtesy light with time delay.

MANUAL RELEASE

User-friendly manual release. The installation of the external emergency release device is recommended when the main garage door is the only garage exit (150SESP).

GEARS

A reduction of seven gears,
entirely of carbon steel, guarantees absolute torque and
resistance.

SAFETY

Encoder technology as standard in the SPINQRE version to ensure constant and reliable obstacle control.
