ARM290BI

18 Volt. Automation for gate leaves up to 6 m. Opening time 21 s

650ARM290BI Irreversible DC electromechanical telescopic gate operator with encoder. Maximum gate leaf 6 m. It is also perfect for large pillars. Fixing brackets not included.

Motor power supply

Leaf length max. (m)

Mounting

FEATURES

• residential/apartment building/commercial use
• for gates leaves up to 6 m
• rod extension gate operator
• suitable for large gates and non standard sized posts
• electrical connections are easier thanks to the larger upper space
• manual release with key lock
• quick and easy installation

PROS

• low voltage DC gate operator
• auto-learning of the gate stroke through optical encoder
• obstacle detection and crush prevention
• in accordance with EN 12453 standards
• works even during power outage thanks to the optional backup battery
• fast operating speed
• soft start and soft stop
• intensive use, ideal for use on apartment buildings and public entrances

B UP TO 595 MM MAX

Thanks to the telescopic extension, it is able to adapt perfectly to the different dimensions of the pillars.

OPTICAL ENCODER

Obstacle detection and anticrushing safety ensured by the optical encoder. The encoder also manages the deceleration in the closing and opening phases and the adjustment of the gate stroke which doesn’t require a limit switch.

EASY INSTALLATION

Thanks to the connections from above, it is more convenient and faster to install and wire.

DOORS OPENING UP TO 125°

Thanks to the versatility of the optional oversized multi-hole brackets (650ARMKITSTFM), the installation is remarkably simplified and it is possible to reach a considerable degree of leaf opening up to a maximum of 125°.
